Sargent – 30amp Battery to Battery (DC-DC) Charger with Canbus

This DC-DC charger offers multi-stage charging of the leisure battery from the vehicle battery. The unit can also be used with smart or traditional alternators and can charge most leisure battery types.Features:Automatic operation when vehicle is started.CAN Bus interface to communicate with other equipment.Protected against overheating, overvoltage, short-circuit and over-current.3-Stage charging profile for effective charging – Depending on battery type selected, the profile will be adjusted to maximise charging performance.Can charge Flooded lead acid, AGM, gel, and lithium batteries.If the vehicle battery voltage becomes too low, the output current will be reduced to avoid overcharging.We would recommend that this charger is installed as close to the leisure battery as possible in a ventilated area with a minimum 10cm gap around to avoid overheating as the cooling fan will emit some warm air.Specification:Battery types – Gel, lead acid, AGMLeisure battery voltage range – 8-16VBattery capacity – 45-280AhVehicle battery voltage range – 10.5-15.4VEfficiency @ 12V – 94%Power (max) – 390WOutput current (max) – 30AD signal voltage range – 8-16VTemperature compensation – 3mV/CStandby current – 17mA (max)Weight – 460gDimensions – 147 x 118 x 41mmOperating temperature – -20-50c
